2.4 GHz: 802.11b/g/n with 256 QAM support
5 GHz: 802.11a/n/ac Wave 2 with 256 QAM support
AWK-1151C US Models Only:
2.412 to 2.462 GHz (11 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320 GHz (4 channels)
5.500 to 5.700 GHz (11 channels)
5.745 to 5.825 GHz (5 channels)
AWK-1151C UN Models Only:
2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320 GHz (4 channels)
5.500 to 5.700 GHz (11 channels)
5.745 to 5.825 GHz (5 channels)
Available channels change depending on the selected country or region code.
WPA/WPA2/WPA3-Enterprise (IEEE 802.1X/RADIUS, TKIP, AES)
WPA/WPA2/WPA3-Personal
2.4 GHz:
802.11b: 1 to 11 Mbps
802.11g: 6 to 54 Mbps
802.11n: 6.5 to 400 Mbps
5 GHz:
802.11a: 6 to 54 Mbps
802.11n: 6.5 to 300 Mbps
802.11ac: 6.5 to 867 Mbps
25±1.5 dBm @ 6 Mbps
23±1.5 dBm @ 54 Mbps
25±1.5 dBm @ MCS0 20 MHz
22±1.5 dBm @ MCS7 20 MHz
24±1.5 dBm @ MCS0 40 MHz
22±1.5 dBm @ MCS7 40 MHz
25±1.5 dBm @ MCS0 20 MHz
22±1.5 dBm @ MCS8 20 MHz
24±1.5 dBm @ MCS0 40 MHz
21±1.5 dBm @ MCS9 40 MHz
23±1.5 dBm @ MCS0 80 MHz
20±1.5 dBm @ MCS9 80 MHz
29±1.5 dBm @ 1 Mbps
29±1.5 dBm @ 11 Mbps
29±1.5 dBm @ 6 Mbps
26±1.5 dBm @ 54 Mbps
28±1.5 dBm @ MCS0 20 MHz
25±1.5 dBm @ MCS7 20 MHz
28±1.5 dBm @ MCS0 40 MHz
25±1.5 dBm @ MCS7 40 MHz
Typ. -89 @ 6 Mbps
Typ. -72 @ 54 Mbps
Typ. -89 dBm @ MCS0 20 MHz
Typ. -69 dBm @ MCS7 20 MHz
Typ. -85 dBm @ MCS0 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
Typ. -88 dBm @ MCS0 20 MHz
Typ. -65 dBm @ MCS8 20 MHz
Typ. -85 dBm @ MCS0 40 MHz
Typ. -60 dBm @ MCS9 40 MHz
Typ. -81 dBm @ MCS0 80 MHz
Typ. -55 dBm @ MCS9 80 MHz
Typ. -96 dBm @ 1 Mbps
Typ. -88 dBm @ 11 Mbps
Typ. -90 dBm @ 6 Mbps
Typ. -74 dBm @ 54 Mbps
Typ. -90 dBm @ MCS0 20 MHz
Typ. -70 dBm @ MCS7 20 MHz
Typ. -87 dBm @ MCS0 40 MHz
Typ. -69 dBm @ MCS7 40 MHz
Client
Client-Router
Slave
Sniffer
External, 2/2 dBi
Omni-directional
2 RP-SMA female
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3az for Energy-Efficient Ethernet
IEEE 802.1Q for VLAN Tagging
IEEE 802.1X for authentication
1
DHCP Server
DHCP Client
DNS
HTTP
IPv4
LLDP
SMTP
SNMPv1/v2c/v3
Syslog
TCP/IP
Telnet
UDP
VLAN
MXconfig
Port forwarding
Static Route
NAT
HTTPS/SSL
RADIUS
SSH
Certificate Management
SNTP Client
ICMP
MAC address
IP protocol
Port-based
Client Isolation
Wi-Fi ACL
RS-232
8-pin RJ45
USB Type A
PWR, WLAN, SYSTEM
Reset button
Metal
IP30
100 x 130 x 22 mm (3.94 x 5.12 x 0.87 in)
436 g (0.96 lb)
DIN-rail mounting
Wall mounting (with optional kit)
9 to 30 VDC, 1.57 to 0.47 A
9 to 30 VDC
1 removable 3-contact terminal block(s)
14 W (max.)
Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
-40 to 85°C (-40 to 185°F)
5 to 95% (non-condensing)
EN 61000-6-2/-6-4
EN 55032/35
CISPR 32, FCC Part 15B Class A
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V/m
IEC 61000-4-8 PFMF: 30 A/m
E mark E1
IEC 60950-1
IEC 62368-1
UL 62368-1
IEC 60068-2-6
EN 300 328, EN 301 489-1/17, EN 301 893, ANATEL, FCC, MIC, NCC, RCM, SRRC, WPC, KC, NBTC, IC
IEC 62443-4-1
IEC 62443-4-2
1,144,888 hrs
Telcordia SR332
