Single Core Teflon Wire

QR code

share

WeChat

Sina Weibo

QQ

QQ space

Douban

Baidu Post Bar

Quantity Single core Teflon wire

Type Medical Wire

Material Tinned copper

Color Natural quality

OD 1.36±0.08

Jacket FEP

Characteristic impedance Not required

138-1629-4533

Attachment Download

DetailDocument

Conductor

Size : 0.5 mm2 1.0 mm2 2.0 mm2

Material： Tinned copper

Stranding： 108/0.08 No./mm 200/0.08 No./mm 400/0.08 No./mm

Insulation

Material： FEP

Thickness： 0.20 mm 0.20 mm 0.20 mm

Diameter ： 1.36±0.08 mm 1.70±0.10 mm 2.25±0.12 mm
